Optical glass refers to glass materials with specific optical properties, which are widely used in various components in optical systems. Optical glass can be divided into many types according to different optical properties, application requirements and material composition. Each type of optical glass has unique composition and properties, suitable for different optical components, such as lenses, prisms, filters, reflectors, etc. Below we will introduce in detail the main types, composition, characteristics and applications of optical glass in optical components.
Ordinary optical glass
Composition
Ordinary optical glass is the most basic optical glass, usually composed of silicon dioxide (SiO₂) as the main component, and contains sodium oxide (Na₂O), potassium oxide (K₂O), aluminum oxide (Al₂O₃) and other components. Common types include crown glass and flint glass.
Crown glass: The main component is silicon dioxide, with a low refractive index (1.5~1.6) and small dispersion, which is suitable for optical systems that require a lower refractive index.
Flint glass: Contains more lead oxide, has a higher refractive index (1.6~1.9), but has a larger dispersion, and is suitable for optical components with high refractive index requirements.
Characteristics
The refractive index range is moderate (1.4~1.7).
Good dispersion performance, can be used to correct chromatic aberration.
Easy to process and relatively low cost.
Application
Mainly used to make basic optical components such as ordinary lenses, prisms, microscopes, telescopes, etc.
High refractive index optical glass
Composition
High refractive index optical glass increases the refractive index of glass by adding high refractive index oxides such as titanium oxide (TiO₂), zirconium oxide (ZrO₂) or lead oxide (PbO). Some high refractive index glasses are lead-free, using bismuth oxide (Bi₂O₃) instead of lead.
Features
High refractive index (above 1.8~2.0) can significantly enhance the focusing ability of light.
Suitable for optical components in multi-lens systems.
The dispersion is large, so special attention should be paid to the correction of chromatic aberration during design.
Application
Commonly used in high-performance lenses and prisms in camera lenses, projection lenses, and laser systems.
Low dispersion optical glass
Composition
Low dispersion optical glass is based on borosilicate, with the addition of elements such as strontium oxide (SrO), barium oxide (BaO) or fluorides (such as CaF₂), which can effectively reduce the dispersion of light.
Features
It has a high Abbe number (vd>50v_d > 50), which can effectively reduce chromatic aberration.
It has small dispersion and is suitable for high-precision imaging systems, especially in applications requiring high optical precision.
Application
It is suitable for astronomical telescopes, microscopes, high-precision camera lenses, etc., especially optical elements that require achromatic aberration.
Infrared optical glass
Composition
Infrared optical glass is generally composed of germanium (Ge), sulfur (S), selenium (Se) and fluorides (such as CaF₂). Germanium glass, chalcogenide glass and fluoride glass are common infrared materials.
Features
It has excellent infrared transmittance and is suitable for mid-infrared to far-infrared bands (2~12 µm).
Low absorption and scattering, which can achieve efficient infrared imaging.
Applications
It is widely used in infrared imaging lenses, thermal imaging equipment, night vision systems and infrared spectrometers.
UV optical glass
Composition
Ultraviolet optical glass is usually composed of pure silicon dioxide (SiO₂) or fluorides (such as CaF₂, MgF₂). Fused quartz is a common UV optical glass.
Features
It has high transmittance in the UV band (200~400 nm).
High temperature resistance and strong chemical stability, suitable for harsh environments.
Applications
It is used in applications such as UV spectrometers, fluorescence microscopes, and UV laser systems.
High temperature resistant low expansion glass
Composition
High temperature resistant low expansion glass mainly contains high purity silicon dioxide (SiO₂) and a small amount of aluminum oxide (Al₂O₃). Common materials include ULE (ultra-low expansion glass) and Zerodur glass.
Features
The thermal expansion coefficient is extremely low, suitable for environments with high temperature and large thermal changes.
It can maintain optical stability in high temperature environments.
Applications
It is commonly used in space telescope reflectors, laser optical components and large optical astronomical lenses.
Nonlinear optical glass
Composition
Nonlinear optical glass is usually composed of materials with high nonlinear optical effects, such as borates (B₂O₃), niobates (Nb₂O₅) and selenides (Se).
Features
It can produce nonlinear optical effects such as frequency doubling and mixing under strong light excitation.
It has a high optical nonlinear coefficient and is suitable for laser and optical modulation applications.
Applications
It is used for frequency doubling crystals (such as second harmonic generation) and optical modulators in laser systems.
Colored optical glass
Composition
Colored optical glass is usually adjusted by adding transition metal oxides (such as Cr₂O₃, CoO) or rare earth elements (such as Nd, Er) to adjust the transmittance and absorption of light.
Characteristics
It has the ability to selectively absorb or transmit light of specific wavelengths.
It can be used to adjust the spectral characteristics and improve the color performance of optical systems.
Applications
It is mainly used to make color filters, spectrum separation components and laser devices.
Conductive optical glass
Composition
Conductive optical glass is usually glass surface coated with a conductive film (such as indium tin oxide, ITO). This coating makes the glass conductive.
Characteristics
It has good optical transmittance and conductivity.
It can be used in dynamic optical control and electronic optical devices.
Applications
It is used for conductive optical components in touch screens, liquid crystal displays and photovoltaic devices.
Anti-reflection glass (AR glass)
Composition
AR glass is usually treated with nano-coating or micro-structures on the glass surface to reduce reflection and increase transmittance.
Features
It can significantly reduce surface reflection (transmittance can reach more than 99%), thereby improving light transmittance.
Excellent anti-glare performance, suitable for high-quality imaging applications.
Applications
Widely used in displays, anti-glare screens, solar photovoltaic panels, etc.
Summary
There are many types of optical glass, and according to their different compositions and characteristics, they are suitable for optical components in different fields. Optical glass plays a vital role in both ordinary optical instruments and high-end applications such as infrared imaging, ultraviolet spectroscopy, laser systems, etc. With the continuous development of optical technology, the continuous emergence of new optical glass materials will promote the innovation and upgrading of optical components to meet the needs of more complex optical systems.
